Camping fridge with freezer Dometic 61l, with gas supply 50 mbar / 12V / 230V,

Description

56l fridge with 5l freezer with 3-way power supply (12V, 230V, gas), ideal for camping, holiday homes, cottages, etc. It works on the absorption principle, using ammonia as refrigerant. The construction of absorption fridges involves no moving parts, so there is no noise. It cools up to 30ºC cooler than the ambient.

The regulator for the cylinder can be purchased here and the connection to the gas cylinder is via a 1/4 left-hand threaded hose which can be purchased here

If you want to power this refrigerator from a 12V battery, you have to make the following calculation: the specifications of the refrigerator indicate a consumption of 1900 W/day. Let's calculate the battery capacity required if the device is battery operated only: 1900 watt hours/day: 12 Volts = approximately 158 Ah/day.
The device has no battery discharge protection. We recommend the additional use of a battery monitor to protect the battery from unwanted discharge.

Specifications

• colour: white
• external dimensions (W x H x D): 48.6 x 61.7 x 49.5 cm
• interior dimensions (width x height x depth): 41 x 47.6 x 25.4
• weight: 24 kg
• fridge volume: 56 litres
• freezer volume: 5l

• gas connection: 50 mbar


• Voltage: 12 V / 220 - 240 V, 50/60 Hz

• Power consumption: 110 W (direct current) / 110 W (alternating current)

• Energy consumption/24h: 1.9 kWh/24 h (direct current) / 1.9 kWh/24 h (alternating current)

• Gas consumption: 16.8 g/h (butane, propane, LPG)

• Cooling capacity: Max. 30 °C below ambient temperature

• Intended use at ambient temperature: 16 °C to 32 °C

• Noise emission: 0 dB

• Refrigerant: 367 g H2O +173 g NH3
