Monocrystalline photovoltaic panel 24V / 215W, Victron "Blue Solar"

Description

Monocrystalline photovoltaic panel 215W, Victron "Blue Solar". Attention !!! This panel is 24V

Features:

- Low voltage-to-temperature coefficient improves operation at high temperatures.
- Exceptional low-brightness operation and high light sensitivity across the full spectrum of sunlight.
- 25-year warranty on output power and performance characteristics.
- 5-year warranty on materials
- Water-resistant, watertight multi-function junction box provides a high degree of security
- High-power bypass diodes minimise shade-induced performance degradation.
- Enhanced EVA (ethylene vinyl acetate) encapsulation with three-layer base plate meets the most stringent safety requirements for high voltage operation.
- Robust anodised aluminium frame ensures modules can be roof mounted using a range of standard mounting systems - High translucency, top quality treated glass provides increased rigidity and impact resistance
- Factory wired quick-connect system with PV-ST01 connectors.

Panel Specifications:

• Maximum Rated Power (Pmax): 215 W
• Maximum Voltage (Volts): 40.1 V
• Max Current (Imp): 5,36 A
• Dimensions: (L x W x H): 158 x 70.5 x 3.5 cm
• Weight: 11,7 kg
• Operating range: -40°C +85°C
• Manufacturer warranty:
  • 25 years at 80% of capacity
  • 5 years for manufacturing defects

Full datasheet you can download here

ATTENTION !!! Due to the size, this item has a fixed transport cost of 30 RON

Fixing brackets must be ordered separately:

• Corner profiles and if necessary connection profiles for 2 panels
• Aluminium profiles
• Set of profiles with cable feed through the ceiling
• It is recommended to glue on the caravan or caravan with "Dekasyl MS-5" or Sikaflex 554 adhesive.
